Connect local equipment
Dual RS232, dual RS485 and 1-Wire interfaces connect wired equipment. LTE Cat. 1 and Bluetooth Low Energy 5.3 add wireless communication.
LX Series / Industrial M2M & IoT
RTCU LX9 eco
Connect signals. Develop the application.
An industrial M2M/IoT gateway combining regional LTE Cat. 1 and Bluetooth Low Energy with analog inputs, relay outputs and NX32L application execution.
Part of the RTCU M2M Platform
From field interfaces to application logic
Field signals. Connected applications.
Bring local equipment signals into a programmable industrial application. The LX9 eco combines serial communication, analog and digital inputs, relay outputs and wireless connectivity.
Work with field signals
Use two configurable analog inputs, five digital inputs and four normally-open relay outputs. Up to four digital inputs support S0 mode with the required supply and configuration.
Choose AC or DC power
The device accepts AC or DC supply and contains a nominal 1 Ah Li-Ion battery. Battery-operation behavior is configurable; external-power loss powers down the unit by default.
| Architecture | NX32L (NX32 for Linux) |
|---|---|
| Main processor | 32-bit ARM Cortex-A7, up to 1 GHz |
| Co-processor | 32-bit Cortex-M4 for power management |
| RAM | 128 MByte |
| System flash | 512 MByte NAND Flash |
| Internal flash drive | Up to 64 MByte |
| Removable storage | Micro SD card |
| Cellular | EMEA LTE Cat. 1; see the technical manual for supported radio bands |
|---|---|
| Bluetooth | Bluetooth Low Energy 5.3 |
| Serial interfaces | 2 × RS232; 2 × RS485 |
| Peripheral bus | 1-Wire |
| USB service | Mini USB-B service/programming port |
| Ethernet | Not included |
| Digital inputs | 5, including an ignition/wakeup input |
|---|---|
| S0 inputs | Up to 4 IEC62053-31 Class A inputs; require at least 16 VDC or AC supply and configuration |
| Relay outputs | 4 normally-open AC/DC relay outputs; see manual for switching limits |
| Analog inputs | 2; 0–10 V / 0–20 mA, up to 12-bit resolution (10-bit default) |
| Expansion | Standard Modbus I/O modules |
| DC supply | 8–36 VDC |
|---|---|
| AC supply | 100–260 VAC, 50/60 Hz |
| Internal battery | 1 Ah nominal Li-Ion with intelligent charging |
| Backup behavior | Power-down on external supply loss by default; configurable |
| Enclosure | Polycarbonate plastic with TPE gasket; IP65 |
| Dimensions | W 130 × H 180 × D 60 mm, excluding external connectors |
| Operating temperature | −40 to +60 °C; battery charging has separate limits |
Plan your setup
Models & ordering
Choose the configuration for your installation and include the required region, interfaces and quantity in your enquiry.
Request a quote for this modelMinimum local setup
- A Windows PC with RTCU M2M Studio.
- The device, its documented power source and model-specific programming cable. Install the driver required for that connection.
- Antennas for the radio interfaces you use; a SIM and service subscription if the application uses cellular connectivity.
Remote M2M Studio access adds network connectivity and the RTCU Communication Hub. The Deployment Server is optional for managed remote updates.
Product resourcesFrom evaluation
From evaluation
to installation.
Download the model-specific data sheet, technical manual and applicable declaration, alongside the RTCU open-source license notices.
